1. Structure & Frame
Material: MS (Mild Steel), GI (Galvanized Iron), or Aluminum
Frame Thickness: 1-1.5 inches (depending on size)
Type: Welded or Screw-jointed for durability
Corrosion Resistance: Powder-coated or galvanized frame
2. Acrylic or Flex Sheet
Material: High-quality Star Flex (Vinyl) or Acrylic
Thickness:
Acrylic: 3mm-5mm
Flex: 0.30mm-0.35mm
Printing: Eco-solvent, solvent, or UV printing for durability
Finish: Glossy or matte, as per preference
3. Lighting System (Backlit)
LED Type: High-brightness LED modules (waterproof)
Light Source:
White LED (Standard)
RGB LED (Optional for color effects)
Power Consumption: 12V DC (low energy consumption)
Lifespan: 30,000 - 50,000 hours
Wiring: Copper wiring with proper insulation
4. Power Supply (SMPS)
Input Voltage: 110V - 230V AC
Output Voltage: 12V DC / 5A - 10A (depends on size)
Type: Waterproof & shockproof power supply
5. Mounting & Installation
Mounting Options:
Wall-mounted
Hanging with chains
Pole-mounted (optional)
Fittings: Heavy-duty clamps, bolts, and brackets
Waterproofing: Sealed edges to prevent water ingress
6. Customization Options
Shape: Rectangular, square, round, or custom shape
Size: As per requirement (e.g., 4ft x 2ft, 6ft x 3ft, etc.)
Colors: CMYK color printing for vibrant effects
Branding: Vinyl pasting, embossed letters, or UV-printed graphics
7. Durability & Maintenance
Weather Resistance: UV and waterproof
Lifespan: 5-7 years (depending on material quality)
Maintenance: Occasional cleaning for brightness retention
